13.3 / 15 / 15.6 / 17.3 Inch 4k Portable OLED Monitor Battery 1ms Type-C Usb Powered IPSTouch Screen Portable Monitor
Description
Product Description
Outstanding Features:
1. Portable and Touchable
2. Narrow Bezel, CNC aluminum alloy integral molding
3. FHD IPS, and support HDR
4. Full-function Type-C—–Only one line for data and power and support reverse charging
5. With Micro-USB OTG Port, plug in keyboard or mouse, plug and play.
6. Apply to PS3/PS4, Xbox,Switch, Digital Camera,Mobile-phone,desktop and laptop etc devices which with HM or Full-function Type-C output
|
Display
|
Panel Sizediagonal
|
13.3 / 15 / 15.6 / 17.3
|
|
Panel Type
|
TFT OLED
|
|
|
Color
|
Black
|
|
|
Panel P/N
|
ATNA33XC11
|
|
|
Flat/ Curve
|
Flat
|
|
|
Radius of curvature
|
N/A
|
|
|
Aspect Ratio
|
16:9
|
|
|
HDR support
|
YES
|
|
|
Resolution
|
1920*1080（FHD）,3840*2160 4K
|
|
|
Display Viewing AreaH*V mm
|
293.76 H x 165.24 V 13.3”diagonalmm
|
|
|
Panel Backlight Type
|
N/A
|
|
|
Display Surfacenon-glare/ glare
|
glare
|
|
|
Bright Dots
|
Follow Panel IIS
|
|
|
Defect Dots
|
Follow Panel IIS
|
|
|
Pixel Pitch H*V mm
|
153 x 153, Sub Pixel : 51 x 153um
|
|
|
Brightness cd/m2 Typ.
|
Brightness @OPR50%/100%:340cd/m2
|
|
|
Contrast Ratio Typ.
|
100000:1
|
|
|
Dynamic Contrast Ratio
|
By marketing
|
|
|
View AngleH/V
|
Upper/Down/Right/Left
Contrast Ratio ≥10:Over 85˚ |
|
|
Panel bit depth
|
RGB 8bit+2FRC
|
|
|
Display Colors
|
1074M
|
|
|
Response Time
|
1msOn/Off
|
|
|
Refresh Rate Max.
|
60HZ
|
|
|
Flicker-free
|
N/A
|
|
|
Major Chip
|
Scaler PN
|
MST9U25Q1
|
|
Hub solution PN
|
VIGL850G QFN28
|
|
|
Noise cancelling solution PN
|
N/A
|
|
|
Audio solution PN
|
PAM8003/SOP16
|
|
|
RGB controller
|
N/A
|
|
|
RGB LED
|
N/A
|
|
|
Other PN
|
N/A
|
|
|
Security
|
Kensington lock
|
NO
|
|
Battery
|
Capacity
|
2800mAH/7.6V
|
|
Accessories
|
Power Cable1.8m
|
1
|
|
HDMI Cable QTY1.0m
|
1
|
|
|
USB cable type C（1.0m
|
1
|
|
|
Adaptor
|
1
|
Detailed Images
