OEM 10.4 Inch Touch Screen Monitors With Stand Plastic Metal Shell for POS IPS Panel Touch PC

Description

• warrantyyear : 3-Year
• color : Black
• package : Yes
• series : For Business
• aspect ratio : 4:3
• after-sales service : Call Center and on-line Technical Support, Onsite Training and Inspection, Free spare parts, Return and Replacement, Repair, Others
• private mold : Yes
• products status : New
• type : Capacitive
• interface type : usb, VGA
• brand name : OEM
• place of origin : Guangdong, China
• Panel size : 10.4 inch TFT-LCD Touch Screen Monitor
• Display area : 304*228mm
• Standard Resolution : 1024*768
• Number of Colors : 16.2M
• Brightness : 300cd/m2
• Response time : 5ms
• Video input format : analog RGB
• Frequency : 30~80KHz/60~75Hz

Product specification

Panel size	10.4 inch TFT-LCD Touch Screen Monitor
Display area	304*228mm
Standard Resolution	1024*768
Number of Colors	16.2M
Brightness	300cd/m2
Response time	5ms
View angle	Horizontal:160°
	Vertical:140°
Contrase ratio	20.83402778
Video input format	analog RGB
Connector	VGA for video signal
	USB or RS232 for touch
Frequency	30~80KHz/60~75Hz
Power supply	External Power Supply:100 to 240V DC 12V
Operation Environment	Workable Temperature:-10 to 60°C Storage temperature:-20 to 70°C
	Operate relative humidity:20% to 80%;storage relative humidity:10% to 90%
Touch model	Projected Capacitive touch screen
Optional	（resistive touch,SAW,Infrared touch,etc optional
Duration	50000hours
touch validity	>1,000,000
Net weight	6.0 Kgs/pcs,include stable mental base
Gross weight	6.5 Kgs/pcs,include stable mental base
Power consumption	Max 30W
Setup optional	1 provide wall brackets for wall-mounting, VESA 75mm&100mm
	2 provide stable mental base to support the monitor
OSD control	AUTO,+,POWER,-,MENU
	brightness,contrast ratio,auto adjustment,phase position,clock,Languages,function,Install,reset
Touch interface	USB or RS232 optional
Touch response time	2ms
Certificate	CE, ROHS
Warranty	1 year,provide spare parts
Monitor sizenot include base	375*285*55mm
Each unit box size	420*370*155mm
Package size	4pcs in a carton,carton size:650*450*430mm
Operation system	Windows,Linux,Mac.

1. We are hopestar China’s factory with 18 years of history, mature technology and excellent quality. The factory is located in Guangdong, China, covering an area of more than 12,000 square meters, with nearly 200 skilled workers and 7 assembly lines and module production workshops, with a production capacity of 7,000 PCS/day.

2. More than 14 years of experience in display/all-in-one machine/digital photo frame/notebook production.

3.Our products are exported to all over the world, and our customers are from Europe, North America, South America, Middle East, Southeast Asia, Central Asia and Africa.

4. The products have passed CB, CE, FCC, ROHS, SASO, CCC and other certifications.

5. Fast delivery time: 15-30 days after deposit
